General Information
-
Product Type:
Server -
Product Series:
HXAF240c M5 -
Brand Name:
Cisco -
Manufacturer:
Cisco Systems, Inc -
Product Name:
Hyperflex HXAF240c M5 Server -
Product Line:
HyperFlex -
Manufacturer Part Number:
HXAF-SP-240M5SX-P1 -
Manufacturer Website Address:
http://www.cisco.com -
Processor & Chipset
-
Processor Core:
Hexadeca-core (16 Core) -
Processor Manufacturer:
Intel -
Number of Processors Supported:
2 -
Number of Processors Installed:
2 -
Processor Model:
6130 -
Processor Speed:
2.10 GHz -
Processor Type:
Xeon Gold -
Display & Graphics
-
Graphics Controller Manufacturer:
ASPEED -
Graphics Controller Model:
Pilot 4 -
Graphics Memory Capacity:
Up to 16 MB -
Power Description
-
Number of Power Supplies Supported:
2 -
Number of Power Supplies Installed:
2 -
Redundant Power Supply:
Yes -
Maximum Power Supply Wattage:
1600 W -
I/O Expansions
-
Number of Internal 2.5" Bays:
26 -
Number of Total Expansion Bays:
26 -
Hot Swappable Bays:
Yes -
Memory
-
Number of Total Memory Slots:
24 -
Number of Occupied Memory Slots:
12 -
Intel Optane Memory Ready:
Yes -
Memory Technology:
DDR4 SDRAM -
Maximum Memory:
3 TB -
Standard Memory:
384 GB -
Storage
-
Solid State Drive Interface:
M.2 -
Total Solid State Drive Capacity:
240 GB -
Controllers
-
RAID Supported:
No -
Controller Type:
12Gb/s SAS -
Network & Communication
-
Ethernet Technology:
10 Gigabit Ethernet -
Physical Characteristics
-
Height:
3.4" -
Width:
19" -
Depth:
30.2" -
Rack Height:
2U -
Form Factor:
Rack -
Weight (Approximate):
57.54 lb
