General Information
Product Type:
Barebone SystemProduct Series:
C220 M4Brand Name:
CiscoManufacturer:
Cisco Systems, IncProduct Name:
UCS C220 M4 Barebone SystemManufacturer Part Number:
UCSC-C220-M4LManufacturer Website Address:
http://www.cisco.comProcessor & Chipset
64-bit Processing:
YesChipset Manufacturer:
IntelChipset Model:
C610Number of Processors Supported:
2Processor Supported:
XeonDisplay & Graphics
Graphics Controller Manufacturer:
MatroxGraphics Controller Model:
G200eGraphics Memory Capacity:
8 MBMemory
Number of Total Memory Slots:
24Memory Standard:
DDR4-2133/PC4-17000Memory Technology:
DDR4 SDRAMMaximum Memory:
768 GBControllers
RAID Supported:
YesController Type:
Serial ATANetwork & Communication
Ethernet Technology:
Gigabit EthernetI/O Expansions
Number of 3.5" Bays:
4Number of Total Expansion Slots:
2Number of PCI Express x16 Slots:
2Power Description
Maximum Power Supply Wattage:
770 WInterfaces/Ports
Total Number of USB Ports:
2Number of USB 3.0 Ports:
2Physical Characteristics
Height:
1.7"Width:
19"Depth:
31"Rack Height:
1UForm Factor:
Rack-mountableWeight (Approximate):
29 lbSoftware
Operating System Supported:
Windows Server 2012 R2Operating System Supported:
Windows Server 2012Operating System Supported:
Windows Server 2008 R2Operating System Supported:
Red Hat Enterprise LinuxOperating System Supported:
SuSE Linux Enterprise ServerOperating System Supported:
Oracle Enterprise LinuxOperating System Supported:
SolarisOperating System Supported:
Ubuntu ServerOperating System Supported:
CentOS
