Description
Condition:
New
The S-1110-XT Industrial Temperature Media Converters address the need for transparently connecting 10/100/1000 Ethernet equipment that operate in extreme temperatures to fiber optic cable. The S-1110-XT Media Converters will operate in industrial grade temperatures of-40F to +167F (-40C to +75C). Equipment found in traffic management, oil and gas pipelines, weather tracking, industrial and outdoor applications must function in temperatures that cannot be supported by a commercial based media converter. Boasting this extended temperature feature along with a rugged steel casing, the S-1110-XT Media Converter provides an economical path to extend the distance between two industrial devices subjected to harsh environments and severe temperatures such as security cameras, wireless access points, alarms, traffic controllers, sensors and tracking devices.
| Product Type |
Transceiver/Media Converter
|
| Brand Name |
Perle
|
| Manufacturer |
Perle Systems, Inc
|
| Product Model |
S-1110-SFP-XT
|
| Product Name |
S-1110-XT 10/100/1000 to Fiber Industrial Temperature Media Converter
|
| Manufacturer Part Number |
05090750
|
| Manufacturer Website Address |
http://www.perle.com
|
| Green Compliant |
Yes
|
| Green Compliance Certificate/Authority |
RoHS
WEEE
REACH
|
| Ethernet Technology |
Gigabit Ethernet
|
| Network Technology |
10/100/1000Base-T
|
| Number of Total Expansion Slots |
1
|
| Expansion Slot Type |
SFP
|
| Number of Network (RJ-45) Ports |
1
|
| Network (RJ-45) |
Yes
|
| Total Number of Ports |
1
|
| Media Type Supported |
Twisted Pair
Optical Fiber
|
| Maximum Distance Supported |
328.08 ft
|
| Height |
1"
|
| Width |
3.1"
|
| Depth |
4.7"
|
| Form Factor |
Rail-mountable
Rack-mountable
Wall Mountable
|
| Weight (Approximate) |
11.20 oz
|
| Limited Warranty |
Lifetime
|
Specifications
| General Information |
| Product Type |
Transceiver/Media Converter |
| Brand Name |
Perle |
| Manufacturer |
Perle Systems, Inc |
| Product Model |
S-1110-SFP-XT |
| Product Name |
S-1110-XT 10/100/1000 to Fiber Industrial Temperature Media Converter |
| Manufacturer Part Number |
05090750 |
| Manufacturer Website Address |
http://www.perle.com |
| Miscellaneous |
| Green Compliant |
Yes |
| Green Compliance Certificate/Authority |
RoHS |
| Green Compliance Certificate/Authority |
WEEE |
| Green Compliance Certificate/Authority |
REACH |
| Network & Communication |
| Ethernet Technology |
Gigabit Ethernet |
| Network Technology |
10/100/1000Base-T |
| I/O Expansions |
| Number of Total Expansion Slots |
1 |
| Expansion Slot Type |
SFP |
| Interfaces/Ports |
| Number of Network (RJ-45) Ports |
1 |
| Network (RJ-45) |
Yes |
| Total Number of Ports |
1 |
| Media & Performance |
| Media Type Supported |
Twisted Pair |
| Media Type Supported |
Optical Fiber |
| Maximum Distance Supported |
328.08 ft |
| Physical Characteristics |
| Height |
1" |
| Width |
3.1" |
| Depth |
4.7" |
| Form Factor |
Rail-mountable |
| Form Factor |
Rack-mountable |
| Form Factor |
Wall Mountable |
| Weight (Approximate) |
11.20 oz |
| Warranty |
| Limited Warranty |
Lifetime |
|
