General Information
Product Type:
Barebone SystemBrand Name:
AsusManufacturer:
ASUS Computer InternationalProduct Model:
RS520-E8-RS12-E V2Product Name:
RS520-E8-RS12-E V2 Barebone SystemManufacturer Part Number:
RS520-E8-RS12-EV2Manufacturer Website Address:
http://usa.asus.comMiscellaneous
Green Compliant:
YesGreen Compliance Certificate/Authority:
RoHSProcessor & Chipset
64-bit Processing:
YesChipset Manufacturer:
IntelChipset Model:
C612Number of Processors Supported:
2Processor Socket:
Socket LGA 2011-v3Processor Supported:
XeonDisplay & Graphics
Graphics Controller Manufacturer:
ASPEEDGraphics Controller Model:
AST2400Graphics Memory Capacity:
32 MBInterfaces/Ports
Number of SATA Interfaces:
9Total Number of USB Ports:
4Number of USB 3.0 Ports:
2Power Description
Number of Power Supplies Installed:
2Maximum Power Supply Wattage:
770 WInput Voltage:
120 V ACInput Voltage:
230 V ACI/O Expansions
Number of Internal 2.5" Bays:
2Number of Total Expansion Bays:
14Number of 3.5" Bays:
12Number of Total Expansion Slots:
4Number of PCI Express x8 Slots:
3Number of PCI Express x16 Slots:
1Memory
Number of Total Memory Slots:
16Memory Standard:
DDR4-2133/PC4-17000Memory Technology:
DDR4 SDRAMMaximum Memory:
1 TBControllers
RAID Supported:
YesController Type:
Serial ATA/600Network & Communication
Ethernet Technology:
Gigabit EthernetPhysical Characteristics
Height:
3.5"Width:
17.5"Depth:
24.2"Rack Height:
2UForm Factor:
Rack-mountableWeight (Approximate):
33.18 lbSoftware
Operating System Supported:
Windows Server 2012 R2Operating System Supported:
Windows Server 2012Operating System Supported:
Windows Server 2008 R2Operating System Supported:
Red Hat Enterprise LinuxOperating System Supported:
SuSE Linux Enterprise ServerOperating System Supported:
CentOSOperating System Supported:
Ubuntu Server
